Eibach Pro-Truck-Lift Stage 2R Coilover Lift Kit | 2022-2026 Chevy/GMC 1500 2WD/4WD | 0-2.9 in Lift | E86-23-032-06-22
Sale price
$1,565.00
Regular price $1,738.89
Skip to product information
Eibach Pro-Truck-Lift Stage 2R Coilover Lift Kit | 2022-2026 Chevy/GMC 1500 2WD/4WD | 0-2.9 in Lift | E86-23-032-06-22
Sale price
$1,565.00
Regular price $1,738.89
Free shipping over $200. Lower 48, no code needed. 30-day returns.
Good to know before you buy
Fits
- 2022-2026 Chevy Silverado 1500 2WD/4WD
- 2022-2026 GMC Sierra 1500 2WD/4WD
Eibach's PRO-TRUCK-LIFT STAGE 2R combines our threaded height adjustable coilovers and rear reservoir shocks for fine tuning of ride height and maximum off-road capability.
- Stage 2R system featuring Pro-Truck Coilover 2.0s plus Pro-Truck Reservoir rear shocks
- Height adjustable front coilover and external reservoir rear shocks for increased off-road performance
- Anodized 6061-T6 billet aluminum coilover mounts, 46mm piston, monotube design with nitrogen-filled variable force valving
- Individually dyno tested for matched performance and reliability; heavy duty bushing system also cycle tested
- Engineered, tested and manufactured by Eibach in the U.S.A.
Why this coilover lift kit
Stage 2R is the trail spec: threaded 2.0 coilovers up front and piggyback-reservoir rear shocks that carry more oil and shed heat, so damping stays consistent on long washboard and whoops.
At a glance
| Series | Pro-Truck-Lift Stage 2R |
|---|---|
| Part number | E86-23-032-06-22 |
| Position | Front & Rear |
| Lift | 0-2.9 in |
| Drivetrain | 2WD/4WD |
| In the box | Two pre-assembled Pro-Truck Coilover 2.0 front coilovers and two rear Pro-Truck Reservoir shocks (rear lift springs included where Eibach lists a rear height) |
| Shock body | 46mm piston monotube, nitrogen charged, zinc-coated body |
| Warranty | Eibach 2 year limited warranty (wear parts such as bushings 1 year) |
| Made in | Corona, California, USA |
| Availability | Stocked at the distributor, ships in 1-3 business days |
Ride height settings
Threaded-body coilover: ride height set by spring perch position. Forged aluminum, forged steel, or upgraded aftermarket control arms highly recommended for trucks equipped with stamped steel control arms from the factory. Trail Boss and AT4 trims will need to be adjusted to get to OE height (about +7mm of preload).
Before you order
- Forged aluminum, forged steel, or upgraded aftermarket control arms highly recommended for trucks equipped with stamped steel control arms from the factory.
- Alignment required after installation.
- Rear shocks in this system accept 0 to 1.5 in of rear lift; rear lift blocks are sold separately.
- Lift height varies by trim and engine per Eibach: 0-0.4 in front | 0 in rear; 0-2.9 in front | 0-1.5 in rear; 0.4-2.6 in front | 0-1.5 in rear.
- Eibach lists this part for Trail Boss trims as well; fitment kept as published.
- Eibach lists this part for ZR2 trims as well; fitment kept as published.
- Eibach lists this part for AT4 trims as well; fitment kept as published.
- Eibach lists this part for AT4X trims as well; fitment kept as published.
- Eibach installation instructions: D4116, D4195.
Questions
Stage 1, Stage 2 or Stage 2R?
Stage 1 uses lift springs with clip-adjustable Sport shocks: set it and forget it. Stage 2 swaps the front to threaded 2.0 coilovers for infinite height adjustment. Stage 2R adds piggyback-reservoir rear shocks for heat management on long off-road runs. All three share the same rear spring and lift-block compatibility.
Do I need rear lift blocks?
Only if you want the rear higher than Eibach's listed rear height. The rear shocks in every Pro-Truck-Lift system accept the lift Eibach lists; matching Eibach lift blocks are listed under Rear Lift Block Kits for this truck.
Do I need an alignment?
Any change in ride height moves camber, caster and toe. Plan on a four-wheel alignment after installation.
What does the warranty cover?
Eibach 2 year limited warranty (wear parts such as bushings 1 year) against defects in material and workmanship, original purchaser, excluding coatings and wear parts. Claims run through the selling dealer with proof of purchase.
Eibach Pro-Truck systems
| System | Components | Height adjustment | Best for |
|---|---|---|---|
| Pro-Truck-Lift Stage 1 | Lift springs + Sport shocks | Clip positions on front shock | Daily driver, level or lift, best value |
| Pro-Truck-Lift Stage 2 | Coilover 2.0 + rear Sport shocks | Threaded perch, infinite | Heavy bumpers, winches, adjustable stance |
| Pro-Truck-Lift Stage 2R | Coilover 2.0 + rear Reservoir shocks | Threaded perch, infinite | Sustained off-road, towing on rough roads |
About Eibach
Eibach has built springs since 1951 and engineers, tests and manufactures its Pro-Truck shocks, coilovers and Pro-Lift-Kit springs in Corona, California. Springs and lift blocks carry a 5 year warranty, dampers and coilovers 2 years, all to the original purchaser.
