Eibach Pro-Truck-Lift Stage 2 Coilover Lift Kit | 2014-2018 Chevy/GMC 1500 2WD/4WD | 1.75-4 in Lift | E86-23-032-01-22
Sale price
$1,295.00
Regular price $1,438.89
Skip to product information
Eibach Pro-Truck-Lift Stage 2 Coilover Lift Kit | 2014-2018 Chevy/GMC 1500 2WD/4WD | 1.75-4 in Lift | E86-23-032-01-22
Sale price
$1,295.00
Regular price $1,438.89
Free shipping over $200. Lower 48, no code needed. 30-day returns.
Good to know before you buy
Fits
- 2014-2018 Chevy Silverado 1500 2WD/4WD
- 2014-2018 GMC Sierra 1500 2WD/4WD
Does not fit: Trail Boss, ZR2, AT4, AT4X
Eibach's PRO-TRUCK-LIFT STAGE 2 combines our threaded height adjustable coilovers and sport shocks for fine tuning of ride height, delivering improved off-road performance.
- Stage 2 system featuring Pro-Truck Coilover 2.0s plus rear Pro-Truck Sport Shocks
- Front adjustable threaded spring perch to accommodate increased loads and maximum clearance; ERO off-road race spring equipped and compatible
- Anodized 6061-T6 billet aluminum coilover mounts, 46mm piston, monotube design with nitrogen-filled variable force valving
- Individually dyno tested for matched performance and reliability; heavy duty bushing system also cycle tested
- Engineered, tested and manufactured by Eibach in the U.S.A.
Why this coilover lift kit
Stage 2 keeps the Stage 1 rear and swaps the front to threaded-body 2.0 coilovers, so ride height is infinitely adjustable and stays put under a steel bumper, winch or camper weight.
At a glance
| Series | Pro-Truck-Lift Stage 2 |
|---|---|
| Part number | E86-23-032-01-22 |
| Position | Front & Rear |
| Lift | 1.75-4 in |
| Drivetrain | 2WD/4WD |
| In the box | Two pre-assembled Pro-Truck Coilover 2.0 front coilovers and two rear Pro-Truck Sport shocks (rear lift springs included where Eibach lists a rear height) |
| Shock body | 46mm piston monotube, nitrogen charged, zinc-coated body |
| Warranty | Eibach 2 year limited warranty (wear parts such as bushings 1 year) |
| Made in | Corona, California, USA |
| Availability | Distributor stock varies; Eibach factory backorder at time of listing |
Ride height settings
Threaded-body coilover: ride height set by spring perch position.
Before you order
- Forged aluminum, forged steel, or upgraded aftermarket control arms highly recommended for trucks equipped with stamped steel control arms from the factory.
- Alignment required after installation.
- Rear shocks in this system accept 0 to 1.5 in of rear lift; rear lift blocks are sold separately.
- Eibach installation instructions: D3853, D3957.
Questions
Stage 1, Stage 2 or Stage 2R?
Stage 1 uses lift springs with clip-adjustable Sport shocks: set it and forget it. Stage 2 swaps the front to threaded 2.0 coilovers for infinite height adjustment. Stage 2R adds piggyback-reservoir rear shocks for heat management on long off-road runs. All three share the same rear spring and lift-block compatibility.
Do I need rear lift blocks?
Only if you want the rear higher than Eibach's listed rear height. The rear shocks in every Pro-Truck-Lift system accept the lift Eibach lists; matching Eibach lift blocks are listed under Rear Lift Block Kits for this truck.
Do I need an alignment?
Any change in ride height moves camber, caster and toe. Plan on a four-wheel alignment after installation.
What does the warranty cover?
Eibach 2 year limited warranty (wear parts such as bushings 1 year) against defects in material and workmanship, original purchaser, excluding coatings and wear parts. Claims run through the selling dealer with proof of purchase.
Eibach Pro-Truck systems
| System | Components | Height adjustment | Best for |
|---|---|---|---|
| Pro-Truck-Lift Stage 1 | Lift springs + Sport shocks | Clip positions on front shock | Daily driver, level or lift, best value |
| Pro-Truck-Lift Stage 2 | Coilover 2.0 + rear Sport shocks | Threaded perch, infinite | Heavy bumpers, winches, adjustable stance |
| Pro-Truck-Lift Stage 2R | Coilover 2.0 + rear Reservoir shocks | Threaded perch, infinite | Sustained off-road, towing on rough roads |
About Eibach
Eibach has built springs since 1951 and engineers, tests and manufactures its Pro-Truck shocks, coilovers and Pro-Lift-Kit springs in Corona, California. Springs and lift blocks carry a 5 year warranty, dampers and coilovers 2 years, all to the original purchaser.
