Fox 2.5 Factory Series Rear Reservoir Shock Set | 2004-2020 Ford F-150 4WD | 0-1.5 in Lift | 883-24-002
$1,349.95
Skip to product information
Fox 2.5 Factory Series Rear Reservoir Shock Set | 2004-2020 Ford F-150 4WD | 0-1.5 in Lift | 883-24-002
$1,349.95
Free shipping over $200. Lower 48, no code needed. 30-day returns.
Good to know before you buy
Fits
- 2004-2020 Ford F-150 4WD
Does not fit: Tremor, Lightning
T14 fitment includes Raptor trim
Why the FOX 2.5 Factory Series
Serious off-road builds that want race-shop damping in a bolt-on package. This rear reservoir shock set is valved and sized by FOX for the 2004-2020 Ford F-150 4WD running 0 to 1.5 in of lift. The larger body and reservoir carry more oil, so damping stays consistent when the truck is loaded or the trail gets long. FOX shocks are fully rebuildable and re-valvable, so this is the last reservoir shock the truck needs.
At a glance
| Position | Rear |
|---|---|
| Quantity | Two shocks (pair) |
| Body diameter | 2.5 in |
| Shaft | 7/8 in hard chrome plated |
| Architecture | Remote reservoir |
| Adjustment | None (factory tuned for this vehicle) |
| Lift range | For 0 to 1.5 in lift |
| Warranty | Limited one-year warranty (FOX Factory Series, Performance Elite, 3.0 and Live Valve products) |
What is in the box
- Two shocks (pair) with FOX mounting hardware where the application requires it
- FOX installation instructions (also at tech.ridefox.com)
- Reservoirs and hose assembled and charged from the factory
Manufacturer part number 883-24-002. Designed and built by FOX Factory.
Questions
Is this a lift?
No. It is a shock built for the lift range shown. Match the lift range to your leveling or lift kit; a shock that is too short limits droop and a shock that is too long can bottom internally.
Do I need to buy two?
FOX prices this part as a pair; one order covers both sides.
Is it rebuildable?
Yes. Every FOX truck shock can be rebuilt, re-charged and re-valved by FOX Factory or an authorized service center, so it does not become a throwaway part when the seals wear.
What is the warranty?
Limited one-year warranty (FOX Factory Series, Performance Elite, 3.0 and Live Valve products). Warranty is to the original retail purchaser through the place of purchase; keep your Hannah Suspension order confirmation.
FOX truck shock lines
| Line | Body | Architecture | Adjuster | Warranty |
|---|---|---|---|---|
| 2.0 Performance Series | 2.0 in | IFP or remote reservoir | None (CD on select R/R) | Lifetime (IFP) / 1 yr (R/R) |
| 2.5 Performance Series | 2.5 in | IFP, HTO on select | None | Lifetime |
| 2.5 Performance Elite | 2.5 in | Reservoir | DSC dual speed | 1 year |
| 2.5 Factory Series | 2.5 in | Reservoir | DSC where fitted | 1 year |
| 3.0 Factory Race / Series | 3.0 in | Reservoir, internal bypass | None | 1 year |
| 3.2 Factory Race Live Valve | 3.2 in | Reservoir, Live Valve | Electronic | 1 year |
About FOX
FOX Factory has built race-winning dampers since 1974 and supplies factory suspension to Ford, Ram, GM and Toyota off-road trims. Every FOX truck shock is aluminum-bodied, fully serviceable and tuned for the specific vehicle. Limited one-year warranty (FOX Factory Series, Performance Elite, 3.0 and Live Valve products). Hannah Suspension ships genuine FOX parts with full factory warranty; keep your order confirmation, FOX warranties run to the original purchaser.
