Fox 2.0 Factory Series Front Reservoir Shock w/ CD Adjuster | 2011-2019 Chevy Silverado / GMC Sierra 2500HD/3500HD 2WD/4WD | 7-9 in Lift | 980-26-968
$519.95
Skip to product information
Fox 2.0 Factory Series Front Reservoir Shock w/ CD Adjuster | 2011-2019 Chevy Silverado / GMC Sierra 2500HD/3500HD 2WD/4WD | 7-9 in Lift | 980-26-968
$519.95
Free shipping over $200. Lower 48, no code needed. 30-day returns.
Good to know before you buy
Fits
- 2011-2019 Chevy Silverado 2500HD/3500HD 2WD/4WD
- 2011-2019 GMC Sierra 2500HD/3500HD 2WD/4WD
Does not fit: ZR2, AT4X
Why the FOX 2.0 Factory Series
Direct-fit FOX hardware built to the Factory Series specification. This front reservoir shock with CD adjuster is valved and sized by FOX for the 2011-2019 Chevy Silverado / GMC Sierra 2500HD/3500HD 2WD/4WD running 7 to 9 in of lift. The larger body and reservoir carry more oil, so damping stays consistent when the truck is loaded or the trail gets long. FOX shocks are fully rebuildable and re-valvable, so this is the last reservoir shock the truck needs.
At a glance
| Position | Front |
|---|---|
| Quantity | One shock |
| Body diameter | 2.0 in |
| Shaft | 5/8 in hard chrome plated |
| Architecture | Remote reservoir |
| Adjustment | CD compression damping adjuster |
| Lift range | For 7 to 9 in lift |
| FOX size designation | 9.4 in |
| Warranty | Limited one-year warranty (FOX Factory Series, Performance Elite, 3.0 and Live Valve products) |
What is in the box
- One shock with FOX mounting hardware where the application requires it
- FOX installation instructions (also at tech.ridefox.com)
- Reservoir and hose assembled and charged from the factory
Manufacturer part number 980-26-968. Designed and built by FOX Factory.
Questions
Is this a lift?
No. It is a shock built for the lift range shown. Match the lift range to your leveling or lift kit; a shock that is too short limits droop and a shock that is too long can bottom internally.
Do I need to buy two?
This part number is one shock. Order two for a complete axle, or check our matching front or rear shock for the same lift range.
Is it rebuildable?
Yes. Every FOX truck shock can be rebuilt, re-charged and re-valved by FOX Factory or an authorized service center, so it does not become a throwaway part when the seals wear.
What does the CD adjuster do?
The compression damping knob on the reservoir firms or softens the shock through its whole speed range, handy when you alternate between an empty bed and a loaded trailer.
What is the warranty?
Limited one-year warranty (FOX Factory Series, Performance Elite, 3.0 and Live Valve products). Warranty is to the original retail purchaser through the place of purchase; keep your Hannah Suspension order confirmation.
FOX truck shock lines
| Line | Body | Architecture | Adjuster | Warranty |
|---|---|---|---|---|
| 2.0 Performance Series | 2.0 in | IFP or remote reservoir | None (CD on select R/R) | Lifetime (IFP) / 1 yr (R/R) |
| 2.5 Performance Series | 2.5 in | IFP, HTO on select | None | Lifetime |
| 2.5 Performance Elite | 2.5 in | Reservoir | DSC dual speed | 1 year |
| 2.5 Factory Series | 2.5 in | Reservoir | DSC where fitted | 1 year |
| 3.0 Factory Race / Series | 3.0 in | Reservoir, internal bypass | None | 1 year |
| 3.2 Factory Race Live Valve | 3.2 in | Reservoir, Live Valve | Electronic | 1 year |
About FOX
FOX Factory has built race-winning dampers since 1974 and supplies factory suspension to Ford, Ram, GM and Toyota off-road trims. Every FOX truck shock is aluminum-bodied, fully serviceable and tuned for the specific vehicle. Limited one-year warranty (FOX Factory Series, Performance Elite, 3.0 and Live Valve products). Hannah Suspension ships genuine FOX parts with full factory warranty; keep your order confirmation, FOX warranties run to the original purchaser.
